8 BAS-SVN026G-EN
Configuring Settings on the Home Screen
Cool/Heat Mode
• Off: the system will not cool or heat the space.
• Auto: the system switches between cooling and heating automatically to condition the space.
• Cool: the system will only provide cooling to the space.
• Heat: the system will only provide heat to the space.
Fan Mode
• Auto: the system fan runs only when there is a call for either cooling or heating.
• On: the system fan runs continuously in Awake, Return, and Sleep mode. The fan runs when
there is
only a call for either cooling or heating in Away mode.
Schedule Menu
Touch to advance to the Schedule Menu to set Clock, Schedule, Display, Setpoints, Vacation, and
Options.
Override
Touch to switch between, temporary override, permanent override, and schedule control.
Touch Button Legend
Return to Home screen.
Previous and Next screen advancement.
Change setting values.
Reset the instance number on 2/2 Network Instance screen.
Confirms the change to instance number.
R
