UV-SVP01A-EN 5
Installation of New Units
1. Follow all instruction for
installation of classroom unit
ventilators as detailed in UV-
IOM-1 (Installation Operation
Maintenance manual).
2. Disconnect power or disable
the circuit breaker to unit.
3. Run communication link wire
when required. (See wiring
diagram in the unit).
4. Install zone sensor when
required. (See wiring diagram
in the unit and zone sensor
submittals).
5. Reapply power.
6. Check for GREEN Status LED
operation to ensure power
has been made to the Tracer
TM
ZN.520 unit controller.
7. Check for YELLOW Comm LED
operation to help ensure com-
munication has been made to
the Tracer ZN.520 unit control-
ler when required.
Peel IDENTIFICATION TAG from
unit and place in the Appendix of
this document, or on building
plans for future location use. The
actual room location on the tag
may be hand written.
