UV-SVP01A-EN 21
Analog Inputs
Table 6: Analog inputs
Description Terminals Function Range
Zone TB3-1 Space temperature input 5° to 122°F
(-15° to 50°C)
Ground TB3-2 Analog ground NA
Set TB3-3 Setpoint input 40 ° to 115°F
(4.4° to 46.1°C)
Fan TB3-4 Fan switch input 4821 to 4919 (Off)
2297 to 2342 (Auto)
10593 to 10807 (Low)
13177 to 13443 (Medium)
15137 to 16463 (High)
Ground TB3-6 Analog ground NA
Analog Input 1 J3-1 Entering water temperature -40° to 212°F (-40° to 100°C)
J3-2 Analog ground NA
Analog Input 2 J3-3 Discharge air temperature -40° to 212°F (-40° to 100°C)
J3-4 Analog ground NA
Analog Input 3 J3-5 Outdoor air temperature / Generic
temperature
-40° to 212°F (-40° to 100°C)
J3-6 Analog ground NA
Analog Input 4 J3-7 Power port 4-20 mA
J3-8 Universal input
Generic 4-20ma
Humidity
CO2
0 – 100%
0 – 100%
0 – 2000ppm
J3-9 Analog ground NA
Installation and Wiring
