36 UV-SVP01A-EN
Configuration
Setpoints
1. The heating and cooling setpoint high and low limits only apply to the occupied and occupied standby setpoints and are never applied
to the unoccupied setpoints.
Discharge Air Limits
1. The low limit is the temperature at which the controller shuts down the unit to prevent the coil from freezing.
2. The control algorithm is limited to calculating this discharge air temperature based on capacity request.
Freeze Avoidance
The controller disables freeze avoidance when the outdoor air temperature rises 3 °F above the freeze avoidance setpoint.
Table 15: Setpoint defaults
Setpoint Default Valid range
Occupied heating setpoint 71°F 40 to 115°F
Occupied cooling setpoint 74°F 40 to 115°F
Occupied standby heating setpoint 67 °F 40 to 115°F
Occupied standby cooling setpoint 78 °F 40 to 115°F
Unoccupied heating setpoint 60°F 40 to 115°F
Unoccupied cooling setpoint 85°F 40 to 115°F
Heating setpoint low limit
1
40°F 40 to 115°F
Cooling setpoint low limit
1
40°F 40 to 115°F
Heating setpoint high limit
1
105°F 40 to 115°F
Cooling setpoint high limit
1
110°F 40 to 115°F
Thumbwheel setpoint Enable Disable or enable
Table 16: Discharge air limit ranges
Default Valid range
Low limit
1
38 °F 30 to 50°F
Control point high limit
2
150 °F 38 to 150°F
Control point low limit
2
45 °F 35 to 150°F
Table 17: Freeze avoidance setpoint range
Default Valid range
Freeze avoidance setpoint
1
40 °F 20 to 60°F
