UV-SVP01A-EN 33
Binary Outputs
1
1. Trane’s Rover service tool uses the unit type to determine and download the proper default binary output configuration.
2. The normally open/closed configuration item refers to the inactive state of the controlled end device (such as an 2-position cooling valve
output).
Table 10: Binary output summary
Binary output Classroom unit ventilator Valid range
J1-1 Fan high NA
J1-2 Exhaust fan or none NA
J1-3 Fan low NA
J1-4 (Key) NA
J1-5
Cooling valve open NA
Face bypass cool isolation valve Normally open or normally closed
2
2-position cooling Normally open or normally closed
2
DX NA
J1-6 Cooling valve close NA
J1-7 Face bypass damper open NA
J1-8 Face bypass damper close NA
J1-9
Heating valve open NA
Face bypass heat isolation valve Normally open or normally closed
2
Electric heat stage 1 NA
2-position heating Normally open or normally closed
2
J1-10
Heating valve close NA
Electric heat stage 2 NA
J1-11 Outdoor air damper open NA
J1-12 Outdoor air camper close NA
TB4-1/TB4-2 Terminals Output Rating Load Energized Load De-energized
Generic/baseboard heat output TB4-1
12 VA 1 VAC RMS (typical) 24 VAC RMS (typical)
24 VAC TB4-2
Configuration
