Dimensions and Weights
CLCH-SVX009A-EN 15
Table 2. Performance air handler model UCCA data
Nom airflow (CFM)
1500 3000 4000 5000 6000 7000 3500 10,500 12,500 15,000
Unit size 3 6 8 10 12 14 17 21 25 30
Horz unit height (in.) 27.50 32.50 38.00 38.00 41.80 45.60 48.10 54.30 60.60 60.60
Horz unit width (in.) 34.00 47.00 51.00 63.00 71.00 71.00 79.00 79.00 81.00 94.00
Horz unit length (in.) 51.90 54.90 52.30 54.70 54.70 56.20 60.20 60.20 62.90 69.60
Vert unit height (in.) 51.40 61.30 65.10 69.90 80.10 83.80 92.90 99.20 n/a n/a
Vert unit width (in.) 34.00 47.00 51.00 63.00 71.00 71.00 79.00 79.00 n/a n/a
Vert unit length (in.) 34.10 37.10 29.40 32.10 36.10 36.10 42.10 42.100 n/a n/a
Coils
Hydronic/DX coils (galvanized and stainless steel casing)
Area (ft
2
) 2.80 5.60 7.60 9.90 12.30 14.30 16.30 20.40 24.00 28.50
Width (in.) 17.50 22.50 27.50 27.50 30.00 35.00 35.00 43.75 50.00 50.00
Length (in.) 23.00 36.00 40.00 52.00 59.00 59.00 67.00 67.00 69.00 82.00
Velocity (fpm) 537 533 524 504 488 488 522 516 522 527
Dry Weight (lb.)
- 1-row hydronic 2335435365758196114127
- 2-row hydronic 30 47 60 74 92 105 116 140 163 185
- 4-row hydronic 48 79 101 128 157 181 200 252 287 329
- 4-row DX 41 73 95 121 146 169 188 227 263 311
- 6-row hydronic 61 104 134 171 210 243 270 340 390 452
- 6-row DX 55 97 129 163 197 228 255 318 366 433
- 8-row hydronic 77 132 173 221 270 313 349 437 504 586
Wet Weight (lb.)
- 1-row hydronic 29 44 54 66 84 96 103 123 146 163
- 2-row hydronic 38 60 76 94 119 137 150 186 217 246
- 4-row hydronic 61 101 130 165 204 236 261 332 380 436
- 6-row hydronic 79 135 176 223 277 321 357 452 521 604
- 8-row hydronic 100 173 227 289 357 413 461 582 674 783
Steam coils
Area (ft
2
) 1.80 4.40 6.50 8.50 9.80 13.30 15.10 16.80 21.30 25.30
Width (in.) 12.00 18.00 24.00 24.00 24.00 33.00 33.00 36.00 45.00 45.00
Length (in.) 22.00 35.00 39.00 51.00 59.00 58.00 66.00 67.00 68.00 81.00
Velocity (FPM) 818 686 615 588 610 527 562 627 588 593
Weight (lb.) 31 54 75 86 93 122 132 156 239 266
