Dimensions and Weights
18 CLCH-SVX009A-EN
Table 5. VFD Weights (pounds) and Line Input
HP Type FLA RPM
VFD (single Fan) VFD (dual Fan)
Line Input Weight Line Input Weight
1
208 V / 60 Hz / 3 PH 3.50 1800 4.20 10
230 V / 60 Hz / 3 PH 3.00 1800 4.20 10
460 V / 60 Hz / 3 PH 1.50 1800 2.10 10
575 V / 60 Hz / 3 PH 1.20 1800 3.90 20
1.5
208 V / 60 Hz / 3 PH 5.10 1800 6.80 10
230 V / 60 Hz / 3 PH 4.40 1800 6.80 10
460 V / 60 Hz / 3 PH 2.20 1800 3.40 10
575 V / 60 Hz / 3 PH 1.80 1800 3.90 20
2
208 V / 60 Hz / 3 PH 6.50 1800 6.80 10
230 V / 60 Hz / 3 PH 5.80 1800 6.80 10
460 V / 60 Hz / 3 PH 2.90 1800 3.40 10
575 V / 60 Hz / 3 PH 2.40 1800 3.90 20
3
208 V / 60 Hz / 3 PH 9.70 1800 15.20 15 22.00 27
230 V / 60 Hz / 3 PH 8.60 1800 15.20 15 22.00 27
460 V / 60 Hz / 3 PH 4.20 1800 4.80 12 11.00 20
575 V / 60 Hz / 3 PH 3.30 1800 3.90 20 9.00 25
5
208 V / 60 Hz / 3 PH 15.70 1800 22.00 22 42.00 31
230 V / 60 Hz / 3 PH 13.60 1800 22.00 22 42.00 31
460 V / 60 Hz / 3 PH 6.70 1800 8.20 12 14.00 20
575 V / 60 Hz / 3 PH 5.30 1800 6.10 20 11.00 25
7.5
208 V / 60 Hz / 3 PH 22.40 1800 28.00 22 59.40 64
230 V / 60 Hz / 3 PH 19.40 1800 28.00 22 59.40 64
460 V / 60 Hz / 3 PH 9.40 1800 11.00 15 21.00 27
575 V / 60 Hz / 3 PH 7.60 1800 9.00 20 18.00 37
10
208 V / 60 Hz / 3 PH 29.50 1800 42.00 26 59.40 64
230 V / 60 Hz / 3 PH 25.20 1800 42.00 26 59.40 64
460 V / 60 Hz / 3 PH 12.50 1800 14.00 15 27.00 27
575 V / 60 Hz / 3 PH 10.00 1800 11.00 20 22.00 37
15
208 V / 60 Hz / 3 PH 43.40 1800 59.40 59
230 V / 60 Hz / 3 PH 37.80 1800 59.40 59
460 V / 60 Hz / 3 PH 18.50 1800 21.00 22 40.00 31
575 V / 60 Hz / 3 PH 14.80 1800 18.00 20 34.00 64
