6 PART-SVN121A-EN
Removing the Existing VFD and Components
Figure 3. Typical IntelliPak II 90 to 150 ton configuration
Return/
Exhaust
Fan
Fresh Air
Dampers
Supply Fan
Condenser
Fans
Compressor
Section
Heating
Section
Exhaust Damper
Hood
Evap Coil
Evap Coil
Controls
Variable
Frequency
Drive (VFD)
Filter Section
Reheat Coil Option
Fresh Air
Dampers
Return Air Dampers
Variable
Frquency
Drive (VFD)
Variable
Frequency
Drive
Baysens set
2-Pc connection
tubings
Variable
Frequency
Drive
Figure 4. Typical Voyager III 27.5 to 50 ton configuration
VFD ACCESS
