PART-SVN121A-EN 17
Installation of TR200 VFD and Components
TR200 VFD Programming Information
Please refer to BAS-SVX19A-EN (Operating Instructions: TR200), or the most recent version, for complete
programming information.
VFD Programming Parameters
Please follow these instructions for setting the TR200 programming parameters listed in Ta bl e 4 ,
p. 17.
Note: Check to make sure that parameter 1-23 is set to 60 Hz. To check parameter 1-23 press the
[Main Menu] button (press [Back] button if the main menu does not display), use the []
button to scroll down to Load & Motor, press OK, use the [] button to select 1-2, press OK,
and finally use the [] button until parameter 1-23 is displayed. Parameter 1-23 can then
be modified by pressing OK button and using [] and [] buttons. When the desired
selection has been made, press the OK button.
To verify and/or program a VFD, use the following steps:
1. At the unit, turn the 115 volt control circuit switch to the "Off" position.
2. Turn the 24 volt control circuit switch to the "Off' position.
WARNING
Personal Protective Equipment (PPE) Required!
Installing/servicing this unit could result in exposure to electrical, mechanical and chemical
hazards.
Before installing/servicing this unit, technicians MUST put on all Personal Protective
Equipment (PPE) recommended for the work being undertaken. ALWAYS refer to appropriate
MSDS sheets and OSHA guidelines for proper PPE.
When working with or around hazardous chemicals, ALWAYS refer to the appropriate MSDS
sheets and OSHA guidelines for information on allowable personal exposure levels, proper
respiratory protection and handling recommendations.
Table 4. Supply and Exhaust VFD Programming Parameters—Air-Cooled
Condensers
Menu Parameter Description Setting Description
Load & Motor 1-21 Motor Power Set Based on
Motor Nameplate
Set only for
application using
3hp hi- Efficiency
motors. Set to
2.2 kW/3 hp
1-22 Motor Voltage Set Based on
Motor Nameplate
Set only for 380/
415 50 Hz
applications
1-24 Motor Current Set Based on
Motor Nameplate
Sets the motor
FLA
1-25 Motor Speed Set Based on
Motor Nameplate
Sets the motor
RPM
Limits & Warnings 4-18 Current Limit Rated Current
100%
Limits the
maximum current
to motor
Notes:
1. These parameters are motor specific and the actual motor nameplate rating must be used. Do
not use the unit nameplate.
