Trane XR13 User Manual

18-BC83D1-2 9
STEP 2 - Remove the pressure tap cap and
valve cores from both service valves.
STEP 3 - Purge the refrigerant lines and indoor
coil with dry nitrogen.
STEP 4 - Wrap a wet rag around the valve
body to avoid heat damage and continue the
dry nitrogen purge.
Braze the refrigerant lines to the service
valves.
Continue the dry nitrogen purge. Do not re-
move the wet rag until all brazing is completed.
Important: Remove the wet rag before stopping
the dry nitrogen purge.
NOTE: Precautions should be taken to avoid
heat damage to basepan during brazing. It is
recommended to keep the flame directly off of
the basepan.

Trane XR13 Specifications

General

Sound Level	74 dB
Refrigerant	R-410A
Stages	Single-stage
SEER	14
HSPF	8.2
Compressor	Single-stage
Cooling Capacity	1.5 - 5 tons
Warranty	10 year limited warranty on compressor
