LOG Key, Long Push
Displayed readings are continuously logged to successive Memory location #’s and to
USB at the Menu-selected output rate. The Green LED, the Memory # and USB label
remain on continuously.
RECALL Key, Short Push
If Continuous logging is off, a header record consisting of Date, Time Units and Value
Type is transmitted via USB.
If Continuous logging is on, Continuous logging is turned off.
RECALL Key, Long Push
The meter is put into the RECALL mode.
5. Recall Mode
A Long push of the RECALL key enters the RECALL mode from the RUN mode, and the
RECALL label is displayed. The meter no longer takes new readings, but recalls previously
stored readings from memory. The Memory # is shown on the 5-digit (88888) display and
the value stored at that location is shown on the 6-digit main display. If USB has been
selected, the USB label is displayed.
Manual Controls to Change Memory #
Press > MENU to increment the Memory # displayed.
Press < ALARMS to decrement the Memory # displayed.
To set the Memory # directly to a value:
1. Press > PEAK to advance to the next digit of the Memory #. That digit will flash.
2. Press TARE ^ RESET to increment the flashing digit.
When done, press > MENU to save the changed Memory #.
When exiting the RECALL mode and reentering the RUN mode, the next logged data is
to the last Memory # being displayed, unless Memory Protect is enabled, in which case
the next logged data is to the next Memory # after the highest Memory # with stored data.
The RECALL mode can also be initiated by computer. The main display then shows
dnLoAd. When this mode is entered, the computer-selected Memory #’s are displayed
and transmitted via USB to the computer. When done, the meter is reset to the RUN
mode.
LOG Key, Short Push
If Continuous Recall is off (Green LED off): Transmits the displayed value and all
other selected non-value data items over USB. Advances the Memory # and displays
that stored value.
If Continuous Recall is on (Green LED on): Turns Continuous Recall and the Green
LED off. The current Memory # and USB label remain on steady.
