Transducer Techniques SSI User Manual

- 29 -
torque Units of torque
In-oz Inch-ounce
In-lb Inch-pound
ft-lb Foot-pound
kgf-m Kilogram-meter
N-m Newton-meter
kgf-cm Kilogram-centimeter
N-cm Newton-centimeter
PrESSr Units of
pressure
Pa Pascal
psi Pounds per sq. inch
bar Bar
SEtuP First set of meter
setup functions.
0_00 Noise rejection
0 60 Hz environment
1 50 Hz environment
0_00 Scaling method.
(Selection not available
with TEDS)
0 Not used
1 Coordinates of 2 points
2 Reading coordinates of 2 points
0_00 Action of external
control inputs A & B.
* Display Peak or Valley
as selected under ConFG.
“Funct.” resets Peak,
Valley & Latched Alarms.
Ctrl Input A Ctrl Input B Both
0 Meter reset Funct. reset Meter
1 Meter reset Pk or Vy* Meter
2 Meter reset Tare Meter
3 Meter reset Log Meter
4 Funct. reset Pk or Vy* Meter
5 Funct. reset Tare Meter
6 Funct. reset Log Meter
7 Pk or Vy* Tare Funct
8 Pk or Vy* Log Funct
9 Tare Log Funct
A Tare Tare reset Funct
B Valley Peak Funct
ConFG Second set of
meter setup functions.
00000 Conversion rate
Rates are shown for 60
Hz environment. Divide by
1.2 for 50 Hz. See Section
16, “Specifications,” for
corresponding internal
noise levels in µV.
0 60 conversions/sec (Normal rate)
1 120 conversion/sec (Fast rate)
2 240 conversion/sec (Fast rate)
3 480 conversion/sec (Fast rate)
4 960 conversion/sec (Fast rate)
5 1,920 conversion/sec (Fast rate)
6 3,840 conversion/sec (Fast rate)
7 7,680 conversion/sec (Fast rate)
