00000 Displayed value
in response to pressing
the > PEAK key.
0 Peak (Normal or Fast rate)
1 First Peak (Normal or Fast rate)
2 Valley (Normal rate only)
3 Peak (1
st
push), Valley (2
nd
push)
(Normal rate only)
00000 Peak polarity.
Applies only to Fast con-
version rates.
0 Positive Peak
1 Negative Peak
00000 Custom curve
linearization. Normal rate
only.
0 Linear input
1 Custom curve
FiLtr Filter setup
Applies to Normal oper-
ation at 60 or 50 Hz. The
display is always updated
every 16 conversions.
0 Unfiltered value (1 conversion)
1 Filtered value
00000 Peak, Valley,
First Peak source
0 Unfiltered value (1 conversion)
1 Filtered value
0 Batch average of 16 conversions
1 Filtered value
00000 Adaptive filter
threshold
0 Low (normal setting)
1 High (large transients expected)
00000 Filtered value.
Can be applied to 0 read-
ing, serial data output,
alarms, Peak & Valley.
0 Auto filter selects time constant
1 Batch average of 16 conversions
2 Moving avg time const = 0.08 sec
3 Moving avg time const = 0.15 sec
4 Moving avg time const. = 0.3 sec
5 Moving avg time const = 0.6 sec
6 Moving avg time const = 1.2 sec
7 Moving avg time const = 2.4 sec
8 Moving avg time const = 4.8 sec
9 Moving avg time const = 9.6 sec
A No filter. “Displayed reading”
must be set to 1 (Filtered value).
dEC.Pt System decimal
point *
dd.ddd Decimal point
flashes.
.ddddd d.dddd dd.ddd llll
ddd.dd dddd.d ddddd. llll
* If TEDS is connected and Plug & Play is enabled, the decimal point is obtained from TEDS
and not the meter. When changed, the meter displays tEdS instead of StorE .
