Installation (for qualified installers only) 7
© Travis Industries 4090812 100-01232_001
Installation Warnings
 Failure to follow all of the requirements may result in property damage, bodily
injury, or even death.
 This heater must be installed by a qualified installer who has gone through a
training program for the installation of direct vent gas appliances.
 This appliance must be installed in accordance with all local codes, if any; if
not, follow ANSI Z223.1 and NFPA 54(88).
 In Manufactured or Mobile Homes must conform with Manufactured Home
Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a
standard is not applicable, the Standard for Manufactured Home Installations,
ANSI/NCSBCS A225.1. This appliance may be installed in Manufactured
Housing only after the home is site located.
 The heater is designed to operate on natural gas, or propane (LP).
 All exhaust gases must be vented outside the structure of the living-area.
Combustion air is drawn from outside the living-area structure.
 Notify your insurance company before hooking up this heater.
 The requirements listed below are divided into sections. All requirements
must be met simultaneously. The order of installation is not rigid – the
qualified installer should follow the procedure best suited for the installation.
Packing List
 LP Orifices and Orifice Gaskets
 Log Set
 Cove Covers
 Panel Trim Rectangular & Button Plug (see page 19)
 "Fireplace Altered" tag (attach to the fireplace)
 Remote Control
 Cover Plate for Receiver (with screws)
Additional Items Required
 If using lp (propane) a conversion kit is required (sku 94400999 – GSR Stepper Motor Kit)
 Faceplate
 Simpson Duravent 6-5/8" to 3" & 3" Co-Linear Adapter with flashing
 3" Diameter Gas Liner (2)
 Direct Vent Cap (Use Simpson Duravent High Wind Cap)
 Gas Line Equipment (shutoff valve, pipe, etc.)
Items Packed with the Face
 Face with attachment hardware (Note: use the cove covers included with the heater)
 Face Installation Instructions
Order of Installation
1 If the heater is to use LP (propane), convert the appliance (see page 45).
2 Install gas line into the fireplace (do not connect to unit).
3 Position the heater.
4 Connect the gas line and gas vent to the appliance.
5 Install the optional surround panels and trim. Attach the on/off switch.
6 Follow the instructions under "Finalizing the Installation" on page 26.
