SLEDGE
•
13
TRAXXAS TQ
i
RADIO SYSTEM
INSTALLING BATTERY PACKS
1. Pull out on the battery
hold-down using the two
release tabs and lift the hold-
down up.
2. Insert a fully charged
battery/batteries into the
battery compartment with
the High Current Connector
positioned toward the rear
of the model. Note: If using
two batteries, position them in the battery compartment side
by side (2a). If using a single battery, remove the foam block and
install the included foam spacer for proper fitment (2b).
3. Lower the battery hold-down and push it in toward the center of
the truck to snap it closed.
Battery iD
Traxxas recommended
battery packs are equipped
with Traxxas Battery iD. This
exclusive feature allows
Traxxas battery chargers (sold
separately) to automatically
recognize connected battery
packs and optimize the
charge settings for the
battery. This eliminates
the need to worry over
charger settings and menus
for the easiest and safest
charging solution possible.
Visit Traxxas.com to learn
more about this feature and
available Traxxas iD chargers
and batteries.
The Traxxas
High-Current Connector
Your model is equipped
with the Traxxas High-
Current Connector. Standard
connectors restrict current
flow and are not capable of
delivering the power needed
to maximize the output of
the VXL-6s. The Traxxas
connector’s gold-plated
terminals, with large contact
surfaces, ensure positive
current flow with the least
amount of resistance. Secure,
long-lasting, and easy to
grip, the Traxxas connector
is engineered to extract all
the power your battery has
to give.
1
2b2a
OR
