2021 E-Caliber Service Manual
18
Carriage wiper seals and bushings (continued)
Install the IsoStrut into the carriage
1. Removethecompressionsleeve.
2. Carefullypullouttheoilplugfromtheshock.
3. Place the foam blocks into the carriage and position
themagainstthesidesofthecarriage.Donotsoak
thefoamblocksinforkbathoilpriortoinstallation.
4. Lightlyoiltheinsideofthecarriageseals.
5. With the sag o-ring in place on the shock, insert the
shockintothecarriage.
Install the damper body hardware
See IsoStrut section on page 10.
Add oil to the carriage
1. UseasyringetolltheIsoStrutwith15ccof10wt
oil.
2. Firmly press the oil plug back into the aft end of the
shock.Makesurethattheplugistightlyseatedinthe
opening.
3. Install the compression sleeve intotheoilplug.
4. InstalltheIsoStrutrearaxleandendcapnut.Torque
theaxleto10Nm.
Tip: If the compression sleeve will not allow the rear
IsoStrut hardware to pass through, the oil plug is not
fullyseatedintotheshock.(Seestep2.)
5. InstallthefrontIsoStrutwashersandbolts.Torque
theboltsto5Nm.
6. WipeoffanyexcessoilfromtheIsoStrut.
