NX-Platform Hardware Installation and Safety 21
The following traffic throughputs are supported across multiple copper and fiber segments for each model:
Model Supported throughput
TippingPointS2600NX Up to 3Gbps
TippingPointS5200NX Up to 5Gbps
TippingPointS6200NX Up to 10Gbps
TippingPointS7100NX Up to 15Gbps
TippingPointS7500NX Up to 20Gbps
Figure 2. TippingPointNX-Platform IPS - front panel, no modules installed
1. Blank module
2. Stack Master LED
3. Stack LED
4. Bypass LED
5. System Health LED
6. CFast Card
7. Console Port (top) and Management Port (bottom)
8. Power Button
