56 NX-Platform Hardware Installation and Safety
Connector and pinout specifications
This topic provides links to topics with connector and pinout information for the TippingPoint system.
This topic contains the following information:
• RJ-45 (COM) console on page 56
• RJ-45 Ethernet connectors on page 57
• Pluggable transceivers on page 58
RJ-45 (COM) console
Describes and provides an image of the RJ-45 connector.
The following figure displays the RJ-45 connector.
Figure 17. RJ-45 connector
The following table shows the RJ-45 console connector pinouts.
Pin number Signal name
1 Request to Send (RTS)
2 Data Terminal Ready (DTR)
3 Transmit Data (TxD)
4 Ground (GND)
5 Ground (GND)
6 Receive Data (RxD)
