32 NX-Platform Hardware Installation and Safety
SR
multimode
LR
multimode
Nominal Worst case Nominal Worst case
Switch loss 0.6dB 1.0dB 0.7dB 1.0dB
Total module insertion loss 0.8dB 2.0dB 0.9dB 1.9dB
Default I/O module configuration settings
Describes the default I/O module settings.
Configurations for the I/O modules can be changed after they are set to the defaults values. However, the
default settings themselves cannot be changed. These default settings are as follows:
• Module configuration defaults:
• No action necessary to restart the module
• No action necessary to delete the slot configuration
• Network port configuration defaults:
• Auto-negotiation is enabled
• Line speed set to the maximum for this type of port
• Duplex set to full
• Port enabled
• Segment configuration defaults:
• Segments are named according to Segment <slotNum >-<segNum >
• L2FB action of permit all
• Link down synch of hub
• Link down synch wait time of 1 second
Hot-swapping I/O modules
Provides an overview of hot-swapping I/O modules.
