NX-Platform Hardware Installation and Safety 35
Feature LED Color Description
Activity Amber Data traffic passing.
Green The module is configured, in service, and
in good health.
Blinking
amber
The module has been inserted and
powered up, but is not yet recognized by
the software.
Solid amber The module is experiencing a fault.
Module
Health
Status
Off Module is disconnected, still powering
up, or rendered out of service by user.
Off Module in bypass.Bypass Status
Green Module in normal mode (not in bypass).
Model requirements
Provides links to topics that describe power and cabling requirements.
The following topics describe power and cabling requirements for the TippingPointNX-Platform IPS:
• Power requirements on page 35
• Cabling requirements on page 36
Power requirements
Describes the power requirements of the NX-Platform devices.
The TippingPointNX-Platform IPS requires one input of Alternating Current (AC) that must meet the
following requirements:
• AC: Voltage 100 – 240; Current 12 – 6; Frequency 50/60 Hz
• DC: Voltage -40 to -60; Current 24 – 16; SELV
