46 NX-Platform Hardware Installation and Safety
Power supply and fan modules
This topic provides links to installation instructions for power supply modules and fans.
The following subjects are discussed.
• NX-Platform AC power supply on page 46
• NX-Platform DC power supply on page 47
• NX-Platform fans on page 49
Warning!
This product might have more than one power supply source. All power sources must be
removed to de-energize the unit.
Note: This product has serviceable modules and hot-swappable power supplies. It has no other serviceable
parts inside.
NX-Platform AC power supply
Describes how to install the AC power supply.
The NX-Platform device includes two power supply modules. The modules are hot-pluggable, redundant,
and current-sharing, and the device can run with one active module.
Figure 12. NX-platform AC power supply
