TRENDnet TEW-636APB - Package Contents; Physical Details

Wireless Access Point User Guide
4
Package Contents
The following items should be included:
• Wireless Access Point
• Power Adapter
• Quick Start Guide
• CD-ROM containing the on-line manual and setup utility.
If any of the above items are damaged or missing, please contact your dealer immediately.
Physical Details
Front Panel LEDs
Figure 2: Front Panel
Security/WPS
Off - WPS feature is not in use.
On (Blue) - If the LED is on for a while and then off, WPS is processing
successfully.
Blinking (Blue) - WPS feature is currently in use.
Blinking (Amber) - WPS is in error condition.
Power
On - Normal operation.
Off - No power
WLAN
On - Idle
Off - Wireless connection is not available.
Flashing - Data is being transmitted or received via the Wireless access
point. Data includes "network traffic" as well as user data.
Status
On - Error condition.
Off - Normal operation.
Blinking - During start up, and when the Firmware is being upgraded.
