Hardware Interface
LAN Connector: One RJ-45 port, 10/100M auto-
sensed, Auto-MDIX
Communication protocol: HTTP, FTP, TCP/IP, UDP, ARP,
ICMP, DHCP, PPPoE, DDNS,
SMTP, UPnP
CPU: ADMtek 5120
RAM: 16MB
Flash ROM: 4MB
OS: Linux
Power Supply: 5VDC/2.5A, 100~240VAC,
50/60Hz
Power consumption: 6 Watt max.
LED Indicator: Power LED (Blue)
Link LED (Red)
I/O port pin assignment:
Input: 1 set, 2-pin (photo relay; Active
High: 9~40VDC; Dropout: 0
VDC)
Output: 1 set, 2-pin (photo relay, Close
circuit current: 70mA or 100mA;
30Ohm; Open circuit voltage:
240 VAC or 350VDC)
RS-485: Half duplex (to control external
pan/tilt device)
Software
Browser: Internet Explorer 5.0 or above;
Netscape 6.0 or above
Application Software: IPView Pro
