Greenflame Wood Pellet Boiler 15kW
11
Greenflame Auto Fill Motor Set-Up for Long Straight Auger
(Optional)
Relay/Contactor
Motor Supply
(MCB Sized to Suit Motor)
Neutral
Live
Configure Controller to Operate Motor
- In System Menu > Default Settings > set P50 = 2 to
activate the Loading Motor Function.
- In System Menu > Timers > Set: T24 to time duration to
reach the min. level sensor 300 seconds.
- T23 is pre-set to 1200 for the amount of time to fill
hopper.
- Run load to prime auger. (Greenflame 25 waits 30
seconds for Belimo valve).
- Collect pellet in a suitable container – DO NOT FILL
BOILER HOPPER.
- Once primed press ESC from load.
- Re-set Er18 if showing on the display.
- Time how long it takes to fill hopper and
increase/decrease T23 if required.
