Greenflame Wood Pellet Boiler 15kW
13
5. Control System
Function: Ignition,
Extinguishing by pushing the
button for 3 seconds until the
acoustic signal.
Function: Unblock. When the
system is in block by pushing
the button for 3 seconds until
the acoustic signal.
In modify mode change menus
and submenus values.
In menu run on submenu and
menu
Function: Exit managed
pushing the button if in a menu
or a submenu. Out of menu
“Pump Test”
Function: Enter in a menu or in
a submenu
Enter in modify mode into a
menu
ENABLE CHRONO
PROGRAMMING
In Chrono menu – Chrono
program: enables the selected
program.
To lock keyboard keys keep this
button pressed for 3 seconds.
To unlock repeat the same
procedure.
Error activation safety thermostat high voltage
Error activation pressure switch (only with the
exhaust fan on)
Accidental extinguishing for low exhaust
temperature
Encoder error.
Error can occur for lack of encoder signal.
Encoder error.
Error can occur in case of adjustment problems of
rounds number
Extinguishing from lack of pellets
Burner cleaning system fault
*Only for product with encoder.
5.1 Error Codes
In the unlikely event that the appliance fails to start or shuts
down unexpectedly, then the error code shown on the
display will give an indication as to the potential cause of the
problem. Some of the errors can be cleared by the house
holder and they are.
Er01 – Water Safety Thermostat – Press the reset button A
and then hold button B for three seconds to clear the error
from the controller.
Er03 – Accidental Extinguishing for Low Exhaust
Temperature – Empty any un-burnt pellets from the burner
pot and hold button B for three seconds.
Er04 – Water over temperature – Hold button B for three
seconds. If the problem persists contact your service agent.
Er12 – Failed Ignition – Empty any un-burnt pellets from the
burner pot and hold button B for 3 seconds.
Er15 – Loss of Voltage – Usually occurs after a power-cut.
