Greenflame Wood Pellet Boiler 15kW
15
Remove the slider plate
under the grate before
removing the ash pan.
Remove the burner pot.
Always replace the slider
plate once the ash pan
has been emptied.
Ash pan full. Carefully
remove ash and empty
into a metal container.
Carefully remove the ash
pan and dispose of the
ash into a metal
container.
Remove any ash from pot
using the tool provided.
Secondary ash pan area.
Carefully remove secondary
ash pan and dispose of ash
into a metal container.
The secondary ash pan is located under the main combustion
chamber. This needs to be emptied less frequently.
Secondary ash pan area.
