TRIGA TR-FFT - Page 19

PRELIMINARY: TR-FFT Fire Fighter’s Telephone Manual — LS10309-001TR-E:A 04/28/2021 19
TR-STSR/TR-STSS Installation Installation
.
Figure 3.13 TR-STS Telephone Connection
Figure 3.14 EOL Example
Contact EOL set to
Connected
*See Figure 3.14 for
EOL example
To:
TR-FFT Audio
or
TR-FPJ Audio
or
TR-STSS Audio
Connect to the TR-FFT to SLC
Terminal TB4 connectors or
the other mini-monitors
Audio -
Audio +
