Trimax SnakeS2 User Manual

TRIMAX SNAKE S2 OPERATORS MANUAL
ENGLISH EDITION
©Trimax Mowing Systems (NZ) Ltd
www.trimaxmowers.com 66 27 March 2019
Tail lights fail to operate
Plugs & sockets not
connected
Check all connections
Wiring damaged
Repair or replace
Roller or spindle
bearings fail
Water in bearings
Do not direct hoses or pressure washers at
bearings
Primary driveshaft CV
joint breaks
Driveshaft angle
exceeds 80°
Limit turn angles, especially when reversing
Poor cut or spread on
side decks only
Blades turning
backwards
Chassis gearbox fitted incorrectly. Un-bolt
gearbox & rotate 180 degrees.
Wheels skid &
damage turf while
mowing
Brakes operating when
mowing decks are
lowered
Turn off electric brakes
Left or right mower deck
guide plates misaligned
with rollers on chassis
when deck in transport
position.
Outrigger bent
Replace outrigger. Consult dealer or Trimax
Mowing Systems.
Pitch & roll pivots loose
or worn
Inspect pitch & roll pivots, tighten or repair
Outrigger hydraulic
cylinder clash
Outrigger hinge shims
not installed correctly or
worn
Insure shim 418-000-001 is installed on the
correct side of hinge to space cylinder from
guide mount plate
Primary driveshaft CV
joint breaks
Driveshaft angle
exceeds 80°
Limit turn angles, especially when reversing
