Trimble R1 User Manual

1 Introduction
l Support notes – Support notes describe any known issues and offer solutions or workarounds
that may be required throughout the life of the product.
These documents can be downloaded from the Trimble website at
www.trimble.com/Support/Support_AZ.aspx. Select the product you need information on.
If you have a problem and cannot find the information you need in the product documentation,
contact your local dealer.
Trimble R1 GNSS Receiver User Guide 10

Trimble R1 Specifications

General

Receiver Type	GNSS
GNSS Signals Tracked	GPS, GLONASS, Galileo, BeiDou, QZSS
Channels	44
SBAS	Yes
Data Logging	Yes
Bluetooth	Yes
Wi-Fi	No
Weight	187 g (6.6 oz)
Operating Temperature	-20 °C to +60 °C (-4 °F to +140 °F)
IP Rating	IP65
Connectivity	Bluetooth
Dimensions	11.2 cm x 6.8 cm x 2.7 cm (4.4 in x 2.7 in x 1.1 in)
