Trimble R1 User Manual

1 Introduction
What's in the box
l R1 GNSSreceiver
l USBcable
l International adaptor kit
l Belt pouch / clip
l Quick Start Guide
Accessories
The following accessories are available for purchase to use with the R1 GNSSreceiver:
l Belt pouch / clip
l Pole pouch
l External antenna
Supported software
You can use the following Trimble software with the R1 GNSSreceiver:
l TerraFlex™ mobile software
l TerraSync™ software
l Positions™ ArcPad extension
l GPSPathfinder® Field toolkit
If you are not using Trimble field software, use the Trimble GNSSStatus utility to manage the
connection to the R1 GNSSreceiver. See Using the GNSSStatus utility, page 16.
For full details of compatility with Trimble software, refer to the Product Compatibilty List. For
information on using the receiver with Trimble field software, refer to the documention for the
software you are using.
Related information and technical support
Product updates, documentation, and any support issues are available for download on the
Support area of the Trimble website (www.trimble.com/Support/). Sources of related information
include the following:
l Release notes – The release notes describe new features of the product, information not
included in the manuals, and any changes to the manuals.
Trimble R1 GNSS Receiver User Guide 9

Trimble R1 Specifications

General

Receiver Type	GNSS
GNSS Signals Tracked	GPS, GLONASS, Galileo, BeiDou, QZSS
Channels	44
SBAS	Yes
Data Logging	Yes
Bluetooth	Yes
Wi-Fi	No
Weight	187 g (6.6 oz)
Operating Temperature	-20 °C to +60 °C (-4 °F to +140 °F)
IP Rating	IP65
Connectivity	Bluetooth
Dimensions	11.2 cm x 6.8 cm x 2.7 cm (4.4 in x 2.7 in x 1.1 in)
