Operational Details
The KVAR Based Controller NEWTON+ is a versatile meter, with all the features
needed to implement a robust electrical load management system. It can be
configured to suit most PF correction and communication needs and, is also
achieved by making as many parameters field programmable as much as possible.
There are basically two modes of operation in NEWTON+:
1. Programming Mode
2. Run Mode
After supplying power (80 VAC - 240 VAC) to the three phases, the unit displays
immediately power receiving information, - - - TRINITY- - - - on LCD
screen and by default, the display comes into Run Mode such as shown below.
Now, the unit can be operated by using the following keypad provided for both the
Programming Mode and Run Mode such as shown below.
VOLT=235.3

Trinity Newton+ Specifications

General

Function	General Purpose
Mechanical Life	10, 000, 000 operations
Ambient Temperature	-40°C to +70°C
Contact Configuration	DPDT
Contact Rating	10A
Coil Voltage	5VDC, 12VDC, 24VDC, 48VDC
Electrical Life	100, 000 operations
Insulation Resistance	1000 MΩ (min) at 500VDC
Vibration Resistance	10-55Hz, 1.5mm
