NEWTON+ – Operational Manual
TRINITY
[15]
3. In case, your setting is completed, press key for about 4 to 5 seconds to
return into Run Mode. Or press
and keys to specify for other
parameters such as above instructions.
8. Setting OFF Delay with Leading PF
In case of PF control action, Off Delay is freely programmable from 10 to 20. If the
system PF falls below the target PF with leading PF, the unit checks whether the
switching capacitor could be persistent or no. If target PF is not achieved, the relay
switches off the first capacitor on in order to correct PF with a FIFO mode of control
action.
To set the Off Delay, proceed the following instructions:
1. In Run Mode, press
key for about 4 to 5 seconds and then the unit will
enter into Programming Mode. Press
key to receive the Off Delay such as
shown below.
2. Press
key. Immediately, P starts blinking which shows that the parameter
can now be changed. Set the desired Off Delay by pressing
and keys
and then, press
key to confirm the parameter setting.
3. In case, your setting is completed, press
key for about 4 to 5 seconds to
return into Run Mode. Or press
and keys to specify for other
parameters such as above instructions.
9. Selecting a Capacitor Bank Stages
NEWTON+ supports upto 8 capacitor bank Stages. For user’s system requirement,
the number of Stages can be selected from 2 to 8 so as to operate the KVAR control.
To select the Stages, proceed the following instructions:
1. In Run Mode, press
key for about 4 to 5 seconds and then the unit will
enter into Programming Mode. Press
key to receive the Bank Stage such
as shown below.
STAGE=8
OFF DELAY=10
