Trinity Newton+ User Manual

NEWTON+ – Operational Manual
TRINITY
[23]
P.O No. : …………………………………………………………………
Customer : …………………………………………………………………
Sr. No. : …………………………………………………………………
Routine and function tests conducted to relevant standards and our
Specifications/Literature/O & M Manual.
Traceability: tested against latest "MTE" Standard Model PRS400.3 having basic
accuracy of 0.02% traceable upto International Standards derived using appropriate
ratio techniques.
Result of Test : …………………………………………………………………
Remarks : …………………………………………………………………
Test engineer : …………………………………………………………………
Date : …………………………………………………………………

Trinity Newton+ Specifications

General

Function	General Purpose
Mechanical Life	10, 000, 000 operations
Ambient Temperature	-40°C to +70°C
Contact Configuration	DPDT
Contact Rating	10A
Coil Voltage	5VDC, 12VDC, 24VDC, 48VDC
Electrical Life	100, 000 operations
Insulation Resistance	1000 MΩ (min) at 500VDC
Vibration Resistance	10-55Hz, 1.5mm
