CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 16
WIRING INFORMATION 2002 Ford F-Series Light Duty
WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW and LT.GREEN/PURPLE
12V IGNITION WIRE DK.BLUE/LT.GREEN
SECOND IGNITION WIRE GRAY/YELLOW
THIRD IGNITION WIRE LT.BLUE/PINK
12V ACCESSORY WIRE RED/BLACK
SECOND ACCESSORY WIRE BLACK/GREEN
STARTER WIRE RED/LT.BLUE
Ignition harness
PARKING LIGHTS (+) BROWN At Headlight Switch Or Gray
Connector Under Dash On
Driver’s Side Right Of Steering
Column
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DRIVER DOOR TRIGGER (-) BLACK/YELLOW Harness In Driver’s Kick Panel
PASSENGER DOOR TRIGGER (-) BLACK/PINK Harness In Pass. Kick Panel
REAR DOORS TRIGGER (-) BLACK/LT,BLUE Harness In Driver’s Kick Panel
DOMELIGHT SUPERVISION (+) BLACK/LT.BLUE Harness In Driver’s Kick Panel
FACTORY ALARM ARM (-) Arms with lock w/ door open
FACTORY ALARM DISARM (-) DK.GREEN/PURPLE Harness In Driver’s Kick Panel
TACHOMETER 4.2L models:
DK.BLUE/LT.GREEN
4.6L models: PINK/WHITE
5.4L models: LT.GREEN/WHITE
At Ignition Coil
BRAKE WIRE (+) LT.GREEN Brake switch
HORN TRIGGER (-) DK.BLUE Steering column
LEFT FRONT WINDOW UP ORANGE/WHITE At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN WHITE/BLACK At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP WHITE/YELLOW Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN TAN/BLUE Harness In Driver’s Kick From
Driver Door
Vehicles with all wheel anti-lock brakes do not have a third ignition wire
Some models are equipped with Ford’s PATS anti-theft system. This needs to be bypassed when
installing a remote start system
