CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 19
WIRING INFORMATION 1997 Ford F-Series Super Duty
WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition harness
12V IGNITION WIRE RED/LT.GREEN Ignition harness
STARTER WIRE RED/LT.BLUE Ignition harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition harness
SECOND ACCESSORY WIRE BLACK/GREEN Ignition harness
THIRD ACCESSORY WIRE GRAY/YELLOW (18-gauge) Ignition harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DOOR TRIGGER (+) BLACK/BLUE Harness In Driver’s Kick Panel
DOME LIGHT SUPERVISION (+) Use Door Trigger Wire
FACTORY ALARM ARM Arms with lock
FACTORY ALARM DISARM (-) DK.GREEN/PURPLE Harness In Driver’s Kick Panel
TACHOMETER WIRE TAN/YELLOW
WHITE/PINK (Diesels)
At Ignition Coil
Behind Instrument Cluster
BRAKE WIRE (+) LT.GREEN Brake switch
HORN TRIGGER (-) DK.BLUE Steering column
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
To Next Page
