CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 2
WIRING INFORMATION 1988 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire
reverse polarity, test using
driver’s door lock switch)
BLACK/ORANGE At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire
reverse polarity, test using
driver’s door lock switch)
PINK/GREEN At Harness In Passenger Kick
Panel
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
