Triple S Customs Car Security - WIRING INFORMATION 2002 Ford F-Series Super Duty

CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 24
WIRING INFORMATION 2002 Ford F-Series Super Duty
WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW & LT.GREEN/PURPLE Ignition harness
12V IGNITION WIRE RED/LT.GREEN Ignition harness
STARTER WIRE GREEN Ignition harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition harness
SECOND ACCESSORY WIRE RED/BLACK Ignition harness
THIRD ACCESSORY WIRE BLUE/LT.GREEN Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (Models
with OEM keyless entry: negative
trigger, models without OEM
keyless entry: 5-wire reverse
polarity- test using driver’s lock
switch)
PINK/YELLOW (models without
factory keyless entry)
WHITE/RED (models with factory
keyless entry)
Models With OEM Keyless:
Module Below Radio
Models Without OEM Keyless:
Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (Models
with OEM keyless entry: negative
trigger, models without OEM
keyless entry: 5-wire reverse
polarity test using driver’s lock
switch)
PINK/GREEN (models without
factory keyless entry)
BLACK/WHITE (models with
factory keyless entry)
Models With OEM Keyless:
Module Below Radio
Models Without OEM Keyless:
Harness In Driver’s Kick Panel
DOOR TRIGGER (+) BLACK/BLUE Harness Right Of Column
DOME LIGHT SUPERVISION (+) Use Door Trigger Wire
TACHOMETER WIRE Non-diesel vehicles: Use any wire
that is NOT RED/LT.GREEN
Diesel vehicles: GREEN or
WHITE
Non-diesel vehicles: At Any
Ignition Coil
Diesel vehicles: At Large
Connector Under Air Intake Duct
BRAKE WIRE (+) LT.GREEN Brake switch
HORN TRIGGER (-) DK.BLUE Steering column
DIESEL WAIT-TO-START Must use pulse timer relay See Page
LEFT FRONT WINDOW UP WHITE/BLACK At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN TAN/BLUE At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP WHITE/YELLOW Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN TAN/BLUE Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW UP GRAY/ORANGE Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW DOWN YELLOW/BLUE Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW UP YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW DOWN RED/BLACK Harness In Driver’s Kick From
Driver Door
Some models are equipped with Ford’s PATS anti-theft system. This needs to be bypassed when
installing a remote start system
