CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 8
WIRING INFORMATION 1994 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
SECOND ACCESSORY WIRE BLACK/GREEN Ignition Harness
THIRD ACCESSORY WIRE GRAY/YELLOW (18gauge) Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE Harness In Driver’s Kick Panel
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Harness Along Firewall By
Brake Pedal
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
