CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 18
WIRING INFORMATION 2004 Ford F-Series Light Duty
WIRE COLOR LOCATION
12V CONSTANT WIRE LT.GREEN/PURPLE
12V IGNITION WIRE DK.BLUE/LT.GREEN
12V ACCESSORY WIRE BLACK/LT.GREEN
STARTER WIRE RED/LT.BLUE
Ignition harness
PARKING LIGHTS (+) BROWN Behind Headlight Or In Blue
Connector At Body Control
Module On Rear Cab Wall
POWER DOOR LOCK (-) PINK/YELLOW Harness In Driver’s Kick Panel Or
In Green Connector At Body
Control Module On Rear Cab Wall
POWER DOOR UNLOCK (-) PINK GREEN Harness In Driver’s Kick Panel Or
In Green Connector At Body
Control Module On Rear Cab Wall
DRIVER DOOR TRIGGER (-) BLACK/YELLOW In Green Connector At Body
Control Module On Rear Cab Wall
PASSENGER DOOR TRIGGER (-) BLACK/PINK In Green Connector At Body
Control Module On Rear Cab Wall
DRIVER REAR DOOR TRIGGER (-
)
BLACK/LT.BLUE In Green Connector At Body
Control Module On Rear Cab Wall
PASSENGER REAR DOOR
TRIGGER (-)
BLACK/WHITE In Green Connector At Body
Control Module On Rear Cab Wall
DOMELIGHT SUPERVISION (+) BLACK/LT.BLUE Harness In Driver’s Kick Panel
TACHOMETER NOT RED/LT.GREEN or RED At Ignition Coil
BRAKE WIRE (+) LT.GREEN Brake switch
HORN TRIGGER (-) DK.BLUE Steering column
LEFT FRONT WINDOW UP TAN/LT.BLUE At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN WHITE/BLACK At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP TAN/LT.BLUE Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN WHITE/YELLOW Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW UP YELLOW/LT.BLUE Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW DOWN GRAY/ORANGE Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
Some models are equipped with Ford’s PATS anti-theft system. This needs to be bypassed when
installing a remote start system
