CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 26
WIRING INFORMATION 2004 Ford F-Series Super Duty
WIRE COLOR LOCATION
12V CONSTANT WIRE LT.GREEN/PURPLE and YELLOW
12V IGNITION WIRE RED/LT.GREEN or
WHITE/YELLOW
12V ACCESSORY WIRE GRAY/YELLOW
SECOND ACCESSORY WIRE RED/BLACK
THIRD ACCESSORY WIRE BLUE/LT.GREEN
STARTER WIRE GREEN
Ignition harness
PARKING LIGHTS (+) BROWN Behind Headlight Switch
IF VEHICLE IS EQUIPPED WITH FACTORY KEYLESS ENTRY
POWER DOOR LOCK (-) WHITE/RED At Vehicle Security Module
Above Transmission Hump
POWER DOOR UNLOCK (-) BLACK/WHITE At Vehicle Security Module
Above Transmission Hump
On vehicles equipped with factory keyless entry, the GEM shuts down a few minutes after the doors have been
locked.
IF VEHICLE IS NOT EQUIPPED WITH FACTORY KEYLESS ENTRY
POWER DOOR LOCK (5-wire) PINK/YELLOW Harness In Driver’s Kick Panel
POWER DOOR UNLOCK (5-wire) PINK/LT.GREEN Harness In Driver’s Kick Panel
Door locks are mastered from the driver’s switch
DOOR TRIGGER (+) BLACK/LT.BLUE Harness In Driver’s Kick Panel
TACHOMETER GREEN/WHITE In Harness Behind Parking Brake
Release
WAIT-TO-START Controlled by a databus, do not interface directly!
BRAKE WIRE (+) LT.GREEN Brake switch
HORN TRIGGER (-) BLUE Steering column
LEFT FRONT WINDOW UP TAN/LT.BLUE At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN WHITE/BLACK At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP TAN/LT.BLUE Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN WHITE/YELLOW Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW UP YELLOW/LT.BLUE Harness In Driver’s Kick From
Driver Door
LEFT REAR WINDOW DOWN GRAY/ORANGE Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT REAR WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
Some models are equipped with Ford’s PATS anti-theft system. This needs to be bypassed when
installing a remote start system
