37
3. Conducting a Remote Session
3.2 Remote Session Toolbar
TheNetCommanderIPprovidesatoolbarthatallowsaremotesessiontobemanipulated.Thefeaturesonthetoolbarallowyoutotoggle
betweenaccessibleports,adjustthevideosettingsoftheremotesession,alignthelocalandremotemousepointers,etc..Whenaremote
session is initiated, the toolbar is displayed briefly in the top-center of the screen, and then collapses to display only a thin bar. To expand
the toolbar, simply move the mouse pointer over the blue bar at the top-center of the screen. The following sections describe the features
available in the remote session toolbar, and how they are used.
3.2.1 Pin Toolbar
Clicking on the Pin Toolbar icon will toggle between displaying the toolbar constantly and allowing it to disappear after a few seconds.
By default, it disappears after a few seconds.
3.2.2 Session
Clicking on the Session iconwilldisplayadrop-downlistoffouroptions;Mount ISO, Unmount ISO, Session Profile, and About.
• Mount ISO – The Mount ISO feature allows you to mount an ISO file to the Target Server as virtual media.
Note:
1. Virtual Media data transfer rates up to 12Mbps are supported. To achieve data transfer rates up to 12Mbps, a B078-101-USB2
must be used.
2. A B078-101-USB-1 can be used to provide Virtual Media support, but only at speeds up to 1Mbps. B078-101-USB and B078-
101-PS2 SIUs are not compatible with Virtual Medial.
3. The ISO file that your are mounting must be located in a Shared Folder of a Samba or NFS file server which is on the same
network that the NetCommander IP is connected to.
To mount the ISO as virtual media:
1. Click on the
icon in the remote session toolbar, and choose the Mount ISO option. The Mount ISO window appears.
2. In the Share Name,typeinthesharenameoftheISOlefromyourSambaorNFSleserver.Forexample,ifthedesiredISOlehas
thepath\\hostname\sharedr\le.iso,theShareNamethatyoushouldtypeis:\\hostname\sharedr.
3. In the ISO Path field, type the direct path to the ISO file. In the example of the previous step, the ISO Path is \file.iso.
4. Selectoneofthefollowingsupportedlesharingmethods:
• Samba (Microsoft Windows)
• NFS (Unix/Linux)
5. For secured file sharing type in a User Name and Password.
6. Click the Mount button. The ISO file is mounted onto the server.
14-03-051 93-32D5.indd 37 3/14/2014 9:52:35 AM
