MODEL: B072 - 016 - 1- IP
RESET
1
1
2
3 4 6
5
1. Product Overview
Console KVM Switch Rear View
1
Power Outlet – The power cord included with the console connects to the unit here.
2
Reset Button – Pressing this button for 10 seconds restores the system to its factory default settings.
3
Serial Ports 1 and 2–TheKVMfeaturestwoRJ45serialportsforconnectingserialmanageabledevices,suchasPDUs,rewalls,and
routers(seetheSerialPinoutsectioninthismanualforthepinoutinformation).
4
LAN Ports 1 and 2–TheKVMfeaturestwoRJ45LANportsforconnectingto10/100Mbpsnetworks.IfLAN1goesdown,LAN2
takesover.WhenLAN1becomesoperationalagain,theKVMwillneedtoberebootedtomakeitthedefaultLANportagain.Note:
Only one LAN port can be turned on at a time; they cannot both be turned on. If you don’t wish to use network redundancy, connect a
single network cable to the LAN 2 Port.
5
USB Port – This port currently serves no functional purpose. It is included for future functionality upgrades.
6
Server Ports–Whenconnectingacomputer/server,Cat5e/6cablingconnectsfromanavailableserverporttoaB078-101-PS2,
B078-101-USB-1 or B078-101-USB2 SIU which in turn connects to the computer/server.
Rackmount KVM Switch Front View
TheNetCommanderIPfrontpanelisillustratedinthegurebelow.Note: The figure below shows a B072-016-1-IP, but the front panel will
be functionally the same for all models.
1
Power LED–ThisBlueLEDilluminatestoindicatethattheunitispoweredon.Nolightindicatesthattheunitispoweredoff.When
aLANredundancyeventoccurs,andLAN2takesoverforLAN1,thisLEDwillblinkslowly.TostoptheLEDfromblinkingaftera
redundancy event, the KVM must be powered off and back on.
14-03-051 93-32D5.indd 7 3/14/2014 9:52:19 AM
