Appendix B. Specification
B.1. SeaKing
B.1.1. SeaKing Dimensions
4000m Rating (standard)
224
Ø99
241
Ø110
Not to scale, dimensions in mm.
Shown with Tritech International Ltd waterblock and 6 pin connector but others are available.
See Appendix E, SeaKing Sonar & Profiler Connector Options for more details and part
numbers.
6800m Rating
224
Ø105
256
Ø110
Not to scale, dimensions in mm.
Shown with a SeaConn 5506 connector but others are available. See Appendix E, SeaKing
Sonar & Profiler Connector Options for more details and part numbers.
