Tritech SeaKing - SeaPrince Dimensions and Properties

Specification SeaKing & SeaPrince Imaging Sonars
0374-SOM-00001, Issue: 08 43 © Tritech International Ltd.
B.2. SeaPrince
B.2.1. SeaPrince Dimensions
Not to scale, dimensions in mm.
153
17
41
77
153
86
17 30
77
Note
Single port model is part number 8249 and dual port is 8250 (a high voltage
version is available which is 8250 48V).
B.2.2. SeaPrince Physical Properties
Depth rating 4000m
Weight in air 1kg (single port), 1.05kg (dual port)
Weight in water 0.39kg (single port), 0.44kg (dual port)
Operating temperature -10 to 35°C
Storage temperature -20 to 50°C
Note
DST SeaPrince units manufactured prior to 2011 have an overall length of
146mm and a maximum diameter of 74.5mm (Single Port) or 86mm (Dual
Port model). If you are unsure which sonar you have please contact Tritech
International Ltd support.
