Triton Electronics AMV3500 - Page 46

© Triton Electronics Ltd 2022 Doc. AMV35003_1.doc v1.04 PAGE 46 OF 52
SAW Recommendations
21
Setup for SAW welding with mutiple
currents
To record in RMS values press the
configure button
Configure the procedure as steps 1-4 but select the
welding process as SAW:
22
By default the AMV3500 uses average
values.
To record in RMS values turn on RMS
Press CLOSE to return to the main
configuration screen
23
Then press DONE to moitor as before
in step 6.
Once the pass is complete follow step
11 on
