Triton t150z User Manual

28
T150Z pumped thermostatic electric shower
BEAB CARE requirements
Check that the Maximum
temperature stop is set to
41ºc (See page 20)
Where installed (Establishment): Location of Unit: Installed/commissioned by: Signed: Date:
*Prior to Installation:
1 2 3 4 5 6 7 8 9 10
Date of Commissioning
Check unit designation
matches the intended
use
dd/mm/yy IW-S 41°C bar bar °C V °C V °C °C
Yes/No Yes/No
a) The inlet filter of the shower is free from debris. b) The in-line check valves or other back-flow prevention devices are in good working order. c) Any isolating valves on the water supplying the unit are fully opened.
Column 7: Columns 8-10: These tests should be performed after resetting the shower to the default running setting by pressing the 'Start' button on the shower cover.
Identification: Date of last calibration:
Supply water pressure Voltage Water temperature
Note: All installation, commissioning and in-service testing must be undertaken by a suitably qualified engineer.
With unit turned on, set the temperature
control to maximum temperature stop
This test should be performed by measuring temperature from a gravity fed cold water tap.
Commissioning
List of Test Equipment Used:
Test equipment used (Model. make, etc)/Method used:
*Prior to Installation check:
Water supply
static pressure (see
page 12 - Water
Requirements).
Water supply
running pressure (see
page 12 - Water
Requirements).
Maximum water
temperature when
water supply is
restricted (see Note 4).
Maximum water
temperature at shower
outlet (see Note 3).
Supply voltage at
appliance Terminals
(see Note 2).
Ambient temperature
of water supply (see
Note 2).
Terminal voltage
(Range: 230V ± 10%).
Water supply
temperature
(Range: 5 - 20°C).
Measurement:
