T30i
16
CLEANING
Before cleaning, turn off the unit at the isolation
switch to avoid the handwash being accidentally
switched on.
Cleaning the sprayhead and rings
The sprayhead is a critical part of the unit
and has been designed to give the maximum
performance.
IMPORTANT: Triton sprayheads ONLY to be
used with this product.
In order to maintain the performance from the
handwash, the spray rings should be cleaned at
regular intervals to prevent build up of deposits
from the water supply.
When first installed it may be required to clean
the spray rings due to debris that may be left
in the pipework after installation, especially if
the commissioning procedure has not been
carried out. Once this initial debris is cleared the
frequency of cleaning will depend upon the type
of water available.
Hard water areas may require cleaning once a
week whereas soft water areas may only require
cleaning every six months.
Note: Blocked spray rings can reduce the water
flow to such an extent that it will cause the
thermal cut-out or PRD to operate.
Procedure
Unscrew the complete sprayhead assembly from
the swivel arm (fig.18). Remove the retaining
screw and withdraw the spray rings (fig.18).
Clean with a suitable brush, ensuring all traces of
scale are removed from the spray ring grooves.
Rinse in clean water and refit the assembly.
Note: The swivel arm has the option of being
fitted with a trim only. If required, unscrew the
sprayhead assembly and push the trim onto the
threaded portion of the arm.
WARNING!
DO NOT use ‘powerful’ abrasive or
solvent cleaning fluids when cleaning
the shower as they may damage the
plastic fittings.
Fig.18
Outlet
arm
Sprayhead 3kW
Trim
Outlet
arm
Sprayhead 7kW
uses two serrated rings
Rings Rings
Retaining screw Retaining screw
Outlet
arm
