T30i
17
SPARE PARTS
Ref. Description Part No.
1. Cover assembly ....................... 81200120
2.
Heater can assembly
3kW ........................... 84500010
7kW ........................... 84500020
3.
Stabilising valve assembly
3kW ........................... 82600730
7kW ........................... 82600720
4.
Thermal cut-out ...................... 22010010
5.
Terminal block & wires ........... 82200110
6.
Pressure Relief Device (PRD) .... 83301330
7.
Outlet pipe assembly .............. 7051619
8.
Swivel arm assembly (200mm)
3kW ........................... 82700080
7kW ........................... 82700090
- 300mm swivel arm ................. 82700100
9. Sprayhead assembly ............... 83302080
- Switch and wire kit (not shown) 3kW
3kW ........................... 82301390
- Switch and wire kit (not shown) 7kW
Micro switch (top) - 7kW ........ 82301370
Micro switch (bottom) - 7kW .. 82301380
ā Filter (not shown) .................... 7052161
