19
FITTING THE COVER
IMPORTANT: Before finally fitting the cover, the
following steps must be taken:
a. Check the plumbing connections are
watertight.
b. Check the terminal block screws are fully
tightened.
c. Make sure the pipe and cable entering
the unit do not prevent the cover locating
correctly to the backplate.
d. Check the power selector is in the OFF
position - and the temperature control
is turned fully clockwise the ‘5 o-clock’
position.
• Offer the cover to the unit.
• Carefully guide the cover onto the backplate
making sure the wires are not trapped.
NOTE: DO NOT remove the cable tie in this unit.
• Guide the cover into position so that the knob
spindle locates correctly (minor adjustment
may be necessary to align the knob and
spindle).
• Should any difficulty arise, re-check the points
above.
• While applying slight pressure to the front
cover, secure in place using the three retaining
screws.
