21
USER OPERATING INSTRUCTIONS
WARNING
If restarting immediately after stopping,
be aware that a slug of hot water will be
expelled for the first few seconds.
10
check list
SECTIONSECTION
OPERATING THE SHOWER - (fig.19)
Make sure the commissioning procedure
has been carried out.
To start the shower
• Press the Start/Stop button and water will flow.
To stop the shower
• Press the Start/Stop button and water will
cease to flow.
• After stopping the unit MUST be isolated via
the 45amp isolating switch.
Power selector
Cold
Economy
High
Temperature
control
Start/Stop
button
COOLER
Fig.19
HOTTER
To use the power selector
The power selector has three positions - COLD,
ECONOMY and HIGH.
Cold setting - single blue line.
• The cold setting does not provide any heat
from the heater can to the incoming water.
Economy setting - single red line.
• Economy uses only one of the elements within
the heater can.
NOTE: If the stated flow rate required for the unit
cannot be met due to low water pressure, it will
be necessary to operate the unit on this setting
during the warmer months because of flow rate
limitations entering the unit.
High Setting - double red lines.
• High uses both of the elements within the
heater can.
IMPORTANT: It will take a few seconds for the
temperature to stabilise once changes have been
made.
